Control system： SIEMENS PLC control system, with stable operation and extremely low failure rate;
Operation system：SIEMENS touch screen, directly visual interface and easy operation, Chinese and English language change conveniently, also with help function and fault display function;
Check system： Use German LEUZE check label sensor, automatic check labeling station, stable and convenient don’t have much higher requirement with worker;
Send label system：use SIEMENS high-power servo control system, stable and high speed；
Parameter SAVE：can save 30 groups labeling parameters, when change bottles, don’t need reset parameters, just adjust the machine part is ok.
Alarm function : label spill, label broken or other malfunction during working,machine will alarm and stop working.
Machine Material：Whole machine and spare parts use material S304 stainless steel and anodized senior aluminum alloy,with high corrosion resistance and never rust;
Labeling way : Servo system;
Low voltage circuit all use German Schneider brand.
Powerrig Machine is one of the toppest double side sticker labeling machine, double side labeling machine, box labeling machine factory.During these years of exporting, Powerrig Machine now has rich experience in the worldwide markets.
|
Model |
MIC-DT60 |
|
Driving Mode |
Servo motor |
|
Yield（pcs/min） |
20-180( depends on bottle and label sizes ) |
|
Operating direction |
Left or Right |
|
Conveyor Speed（m/min） |
≤40 |
|
Labeling Accuracy |
±1.0 mm |
|
Label roll inner diameter |
76 mm |
|
Label roll outer diameter |
350 mm(max) |
|
The suitable size of label |
Standard size: H: 15-180 mm L: 15-300 mm |
|
The suitable size of bottles |
Can customized |
|
Printer device use air |
5kg/cm 2 |
|
Power（w） |
1000W |
|
Weight（kg） |
350 |
|
Conveyor height |
950±50mm (Height can customized) |
|
Machine size |
3000（L） l800（W） 1800（H）mm |
|
Voltage (In China) |
AC220V 50/60HZ Single phase |
|
PLC control system |
SIEMENS |
|
Touch-screen |
SIEMENS |
|
Labeling engine Servo motor |
American AB |
|
Labeling engine Drive |
American AB |
|
photoelectric sensor |
Japan KEYENCE |
|
Photoelectric sensor (Check opaque label） |
German Leuze |
|
Photoelectric sensor (Check opaque and transparent label） |
German Leuze |
|
Main transport motor |
SwitzerlandABB |
|
Press bottle motor |
SIEMENS |
|
Press bottle driver |
SIEMENS |
|
Separate bottle Motor |
German JSCC |
